COMMUNICATIONS
Powering the networks that keep the world connected — from 5G to satellite.
40+ Years
Industry Experience
5G & Mesh Ready
Next-Gen Networks
Fiber Optics
Optical Solutions
End-to-End Testing
Full Validation
Why Communications Teams Trust Calpak
Enabling the Connected World
The communications industry is in an era of unprecedented innovation driven by the demand for data, voice, and video streaming. 5G and new mesh networks are at the center of this transformation — winning in this dynamic landscape requires partners committed to increasing speed, eliminating waste, and accelerating delivery.
"For more than four decades, Calpak has been providing uncompromising service that enables cost-effective scaling."
Leveraging highly integrated solutions, Calpak industrializes customer innovations to meet rigorous performance standards around total cost, quality, reliability, and delivery — consistently delivering best-in-class execution.
What We Do
Strategic Communications Capabilities
From fiber optics to RF manufacturing, we deliver end-to-end solutions for the communications industry.
Fiber Optical Solutions
RF Manufacturing
Design Services
End-to-End Test Solutions
Rapid Prototyping
Lifecycle Management
Quality Assurance
Certifications & Compliance
Every project meets telecommunications and defense-grade quality standards.
Common Questions
Frequently Asked Questions
What RF and controlled-impedance PCB assembly capabilities does Calpak USA offer for communications equipment? +
Calpak USA assembles controlled-impedance PCBs with trace geometries designed to maintain characteristic impedance values typically ranging from 50 to 100 ohms across microstrip and stripline configurations. Our Hawthorne, California facility uses time-domain reflectometry verification to confirm impedance within customer-specified tolerances, typically plus or minus five to ten percent, before populating RF sections. Calpak USA's SMT lines accommodate fine-pitch QFN, BGA, and flip-chip components commonly found in RF front-end modules, low-noise amplifiers, and frequency synthesizer circuits. Our process engineers establish solder paste stencil aperture designs and reflow profiles optimized for RF grounding requirements, including proper thermal relief and via-in-pad configurations. For communications OEMs manufacturing 5G base station electronics, satellite transponders, or microwave backhaul equipment, Calpak USA provides the assembly precision required to preserve signal integrity from bare board through completed PCBA.
How does Calpak USA handle high-frequency substrate materials like Rogers and PTFE laminates? +
Calpak USA has direct experience assembling PCBs fabricated on Rogers RO4000 series, RO3000 series, and PTFE-based Teflon laminates that are standard in RF and microwave communications designs. These materials present unique manufacturing challenges because their lower thermal conductivity and different CTE profiles compared to standard FR-4 require modified reflow parameters and careful thermal profiling. At our Hawthorne, California facility, Calpak USA's process engineers develop board-specific reflow profiles using thermocouple mapping to ensure adequate solder joint formation on high-frequency substrates without delamination or measurable dielectric property degradation. We also handle hybrid stackup constructions where Rogers RF layers are bonded to FR-4 digital layers, a common approach in communications systems that combine analog front-end and digital baseband processing on a single assembly. Calpak USA's material handling procedures account for the moisture sensitivity characteristics specific to each laminate type.
Can Calpak USA assemble mixed-technology boards that combine RF analog sections with high-speed digital circuitry? +
Calpak USA routinely assembles mixed-technology communications boards where RF transmit and receive chains share a PCB with high-speed digital processors, FPGAs, and SerDes interfaces. These assemblies require careful attention to component placement sequencing, selective soldering zones, and shield can installation to maintain isolation between analog and digital domains. Our Hawthorne, California facility programs pick-and-place machines to populate RF sections and digital sections in optimized sequences that respect thermal mass differences and reflow compatibility. Calpak USA installs EMI shield cans and RF compartment lids using solder reflow or epoxy attachment per the design specification. For boards with both leaded and lead-free component requirements, our process engineers develop dual-profile reflow strategies or use selective soldering to accommodate mixed metallurgies. This capability is essential for modern communications platforms where software-defined radio architectures and digital beamforming designs demand tight integration of analog and digital functions.
What testing does Calpak USA perform to verify signal integrity on assembled communications boards? +
Calpak USA implements a layered test strategy for communications assemblies that begins with automated optical inspection to verify component placement accuracy and solder joint quality, followed by in-circuit testing to confirm passive values, semiconductor pin connectivity, and power rail integrity. For RF-specific validation, Calpak USA builds custom functional test fixtures that verify key parameters such as output power, receive sensitivity, frequency accuracy, and spurious emission levels at specified test points on the assembled board. At our Hawthorne, California facility, we work with communications OEMs to develop test procedures that correlate factory-floor measurements with system-level performance specifications. When designs require it, Calpak USA performs boundary scan testing per IEEE 1149.1 for BGA and fine-pitch devices where physical probe access is limited. All test data is logged against serial numbers, providing the traceability documentation that procurement managers require for production acceptance and warranty disposition.
